parameter TD - general use - small icon image
parameter Environment  image
50 ± 5 parameter Hardness image
4 parameter Tensile strength image
1,5 parameter Density image
400 parameter Elongation image
-25 — +80 parameter Temperature range image
1 — 10 parameter Thickness image

Sealing plate intended for general use without special requirements for resistance to negative environmental influences. Made on the basis of SBR rubber compound in black color. With the possibility of specifying the required thickness (1 - 15 mm), width (1,200 - 1,400 mm) and number of inserts (0 - 2 pcs). Click and choose. Complete the exact specification in the configurator.

Complete your specification:

Step 1


Tolerance -

Step 2


Step 3


Tolerance (+/- 10 mm)

Step 4


Step 5


Tolerance (+/- 200 mm)

Step 6




Step 7

Step 8



Produkt TD pouzitie všeobecné použitie - varianty

TD

Id Cislo polozky Stare cislo Skupina Typ Idtrieda Kaucuk Dezen Farba Dlzka Sirka Hrubka Hrubka popis Hmotnost Hustota Pocet vloziek Pocet otlackov
61 TD_7994_00_0_01-0 TD 7994 TD 7994 SBR black 20 1200 1 (+/- 0,2 mm)  1.5 1,5 00 0
62 TD_7994_00_0_01-0 TD 7994 TD 7994 SBR black 20 1400 1 (+/- 0,2 mm)  1.5 1,5 00 0
65 TD_7994_00_0_01-5 TD 7994 TD 7994 SBR black 20 1200 1,5 (+/- 0,2 mm)  2.5 1,5 00 0
66 TD_7994_00_0_01-5 TD 7994 TD 7994 SBR black 20 1400 1,5 (+/- 0,2 mm)  2.5 1,5 00 0
69 TD_7994_00_0_02-0 TD 7994 TD 7994 SBR black 10 1200 2 (+/- 0,2 mm)  3.1 1,5 00 0
70 TD_7994_00_0_02-0 TD 7994 TD 7994 SBR black 10 1400 2 (+/- 0,2 mm)  3.1 1,5 00 0
71 TD_7994_1T_0_02-0 TD 7994 SBR black 10 1200 2 (+/- 0,2 mm)  3.1 1,5 1T 0
72 TD_7994_1T_0_02-0 TD 7994 SBR black 10 1400 2 (+/- 0,2 mm)  3.1 1,5 1T 0
73 TD_7994_00_0_03-0 TD 7994 TD 7994 SBR black 10 1200 3 (+/- 0,3 mm) 4.8 1,5 00 0
74 TD_7994_00_0_03-0 TD 7994 TD 7994 SBR black 10 1400 3 (+/- 0,3 mm) 4.8 1,5 00 0
75 TD_7994_1T_0_03-0 TD 7994 TD 7994 SBR black 10 1200 3 (+/- 0,3 mm) 4.8 1,5 1T 0
76 TD_7994_1T_0_03-0 TD 7994 TD 7994 SBR black 10 1400 3 (+/- 0,3 mm) 4.8 1,5 1T 0
77 TD_7994_2T_0_03-0 TD 7994 SBR black 10 1200 3 (+/- 0,3 mm) 4.5 1,5 2T 0
78 TD_7994_2T_0_03-0 TD 7994 SBR black 10 1400 3 (+/- 0,3 mm) 4.5 1,5 2T 0
79 TD_7994_00_0_04-0 TD 7994 TD 7994 SBR black 10 1200 4 (+/- 0,4 mm) 5.9 1,5 00 0
80 TD_7994_00_0_04-0 TD 7994 TD 7994 SBR black 10 1400 4 (+/- 0,4 mm) 5.9 1,5 00 0
81 TD_7994_1T_0_04-0 TD 7994 SBR black 10 1200 4 (+/- 0,4 mm) 6 1,5 1T 0
82 TD_7994_1T_0_04-0 TD 7994 SBR black 10 1400 4 (+/- 0,4 mm) 6 1,5 1T 0
83 TD_7994_2T_0_04-0 TD 7994 SBR black 10 1200 4 (+/- 0,4 mm) 6 1,5 2T 0
84 TD_7994_2T_0_04-0 TD 7994 SBR black 10 1400 4 (+/- 0,4 mm) 6 1,5 2T 0
85 TD_7994_00_0_05-0 TD 7994 TD 7994 SBR black 10 1200 5 (+/- 0,5 mm) 7.7 1,5 00 0
86 TD_7994_00_0_05-0 TD 7994 TD 7994 SBR black 10 1400 5 (+/- 0,5 mm) 7.7 1,5 00 0
87 TD_7994_1T_0_05-0 TD 7994 SBR black 10 1200 5 (+/- 0,5 mm) 7.5 1,5 1T 0
88 TD_7994_1T_0_05-0 TD 7994 SBR black 10 1400 5 (+/- 0,5 mm) 7.5 1,5 1T 0
89 TD_7994_2T_0_05-0 TD 7994 SBR black 10 1200 5 (+/- 0,5 mm) 7.5 1,5 2T 0
90 TD_7994_2T_0_05-0 TD 7994 SBR black 10 1400 5 (+/- 0,5 mm) 7.5 1,5 2T 0
91 TD_7994_00_0_06-0 TD 7994 TD 7994 SBR black 10 1200 6 (+/- 0,5 mm) 9.4 1,5 00 0
92 TD_7994_00_0_06-0 TD 7994 TD 7994 SBR black 10 1400 6 (+/- 0,5 mm) 9.4 1,5 00 0
93 TD_7994_1T_0_06-0 TD 7994 SBR black 10 1200 6 (+/- 0,5 mm) 9 1,5 1T 0
94 TD_7994_1T_0_06-0 TD 7994 SBR black 10 1400 6 (+/- 0,5 mm) 9 1,5 1T 0
95 TD_7994_2T_0_06-0 TD 7994 SBR black 10 1200 6 (+/- 0,5 mm) 9 1,5 2T 0
96 TD_7994_2T_0_06-0 TD 7994 SBR black 10 1400 6 (+/- 0,5 mm) 9 1,5 2T 0
97 TD_7994_00_0_08-0 TD 7994 TD 7994 SBR black 10 1200 8 (+/- 0,6 mm) 12.5 1,5 00 0
98 TD_7994_00_0_08-0 TD 7994 TD 7994 SBR black 10 1400 8 (+/- 0,6 mm) 12.5 1,5 00 0
99 TD_7994_1T_0_08-0 TD 7994 SBR black 10 1200 8 (+/- 0,6 mm) 12 1,5 1T 0
100 TD_7994_1T_0_08-0 TD 7994 SBR black 10 1400 8 (+/- 0,6 mm) 12 1,5 1T 0
101 TD_7994_2T_0_08-0 TD 7994 SBR black 10 1200 8 (+/- 0,6 mm) 12 1,5 2T 0
102 TD_7994_2T_0_08-0 TD 7994 SBR black 10 1400 8 (+/- 0,6 mm) 12 1,5 2T 0
103 TD_7994_00_0_10-0 TD 7994 TD 7994 SBR black 10 1200 10 (+/- 0,6 mm) 15.5 1,5 00 0
104 TD_7994_00_0_10-0 TD 7994 TD 7994 SBR black 10 1400 10 (+/- 0,6 mm) 15.5 1,5 00 0
105 TD_7994_1T_0_10-0 TD 7994 SBR black 10 1200 10 (+/- 0,6 mm) 15 1,5 1T 0
106 TD_7994_1T_0_10-0 TD 7994 SBR black 10 1400 10 (+/- 0,6 mm) 15 1,5 1T 0
107 TD_7994_2T_0_10-0 TD 7994 SBR black 10 1200 10 (+/- 0,6 mm) 15 1,5 2T 0
108 TD_7994_2T_0_10-0 TD 7994 SBR black 10 1400 10 (+/- 0,6 mm) 15 1,5 2T 0
